Key Control Deadbolt - UL - Square Keyed One Side - featuring SmartKey

817 SMT SQT

Function
Keyed One Side
Finish

The Locksmith's Choice.

We challenged locksmiths at the Associated Locksmiths of America (ALOA) to a picking and bumping contest pitted against the Kwikset SmartKey 980 Deadbolt.

Re-Key to any KW1 Keyway Key

While re-keying your door lock is not a requirement of lock installation, SmartKey allows you to quickly and easily reset your lock's cylinder to work with any KW1 Keyway key.

Features

For use on exterior doors where keyed entry and security is needed
Featuring SmartKey Security™, which protects against advanced break-in techniques and allows you to re-key your lock yourself in seconds.
SmartKey Security™ re-key technology is compatible with Kwikset (KW1) keyway or (SC1) keyway options
Deadbolt operated by key outside and thumb turn inside
Comes with 2 keys
Deadbolt Latch has round corner faceplate
ANSI/BHMA grade 2 certified
Latch has adjustable backset 2-3/8" to 2-3/4" to fit all standard door preparations
Includes round deadbolt strike
1 inch deadbolt throw
Locking mechanism functions with turn piece on the interior of the lock
Meets or exceeds Underwriter Laboratories (UL) testing requirements specified for each product grade or rating
Easily installs in minutes with just a screwdriver
Lifetime mechanical and finish warranty
Microban Antimicrobial product protection keeps door hardware 99.9% cleaner than unprotected surfaces

Specifications

All Measurements are in Inches.

Kwikset Family

816/7 KeyControl Deadbolt

Product Type

Deadbolt

Style

Contemporary

Entry Has SmartKey?

Yes

Has Microban?

Yes

ANSI Grade

Grade 2

UL Time Rating

3 hr

Min Door Thickness

1-3/4

Max Door Thickness

1-3/4

Assembled Height

Assembled Width

2-13/16

Assembled Length

1-9/32

Latch Backset Size

Adjustable

ADA Compliant

Interior Turn Piece Only

Cross Bore

2-1/8"

Support

DOCUMENTS

Note：Do not use prints from this website to mark distances. Due to individual printers, dimensions on installation instructions may not print at an accurate scale.
